Fiber Laser thiab Laser Parts

Vim li cas thiaj xaiv peb?

One-stop Solution

Peb muab cov khoom lag luam ib zaug thiab cov kev pabcuam tshiab rau peb cov neeg siv khoom muaj txiaj ntsig thoob plaws ntiaj teb.Los ntawm cov khoom siv high-chav kawm, mus rau cov khoom siv kho qhov muag tseem ceeb, kho qhov muag kho qhov muag thiab cov modules, kuj muaj cov cuab yeej thiab cov cuab yeej, peb ib txwm muaj rau koj. .

Txhim khu khoom zoo

Peb tsom mus rau kev sib koom ua ke ntsug hauv qhov chaw kho qhov muag, mob siab rau hauv cov khoom lag luam thiab cov kev daws teeb meem hauv cov khoom siv kho qhov muag, kev sib txuas lus kho qhov muag thiab thaj chaw kho qhov muag fiber ntau. Raws li peb nkag siab tob txog kev lag luam sib txawv, thev naus laus zis thiab cov khoom lag luam, peb muab cov kev pabcuam zoo tshaj plaws rau peb cov neeg koom tes thoob ntiaj teb.

Kev Pabcuam Cov Neeg Siv Khoom Zoo

Peb muab kev pabcuam zoo rau cov neeg siv khoom, suav nrog kev pabcuam tomqab muag thiab kev pabcuam kev pabcuam, kom ntseeg tau tias lawv cov neeg siv khoom txaus siab. Lub tuam txhab uas muaj kev pabcuam zoo rau cov neeg siv khoom yuav tsum yog qhov tseem ceeb tshaj plaws rau cov neeg siv khoom vim nws tau lees tias muaj kev lom zem thiab tsis muaj kev ntxhov siab rau kev lag luam.

Ntau yam kev siv

Peb cov neeg tau txais kev pab ntau yam los ntawm kev tshawb fawb lub koom haum, kho qhov muag fiber ntau thiab cable, kev lag luam laser, kev kho mob, kho qhov muag sensing, lidar, optical Cheebtsam, system integration thiab lwm yam.

Fiber Laser yog dab tsi?

Fiber laser yog ib lub laser uas siv iav fiber ntau doped nrog lub ntiaj teb tsis tshua muaj cov ntsiab lus raws li qhov nruab nrab nce. Fiber lasers tuaj yeem tsim los ntawm fiber ntau amplifiers. Nyob rau hauv qhov kev txiav txim ntawm lub teeb twj tso kua mis, siab zog ceev yog yooj yim tsim nyob rau hauv lub fiber, uas ua rau "particle tooj inversion" ntawm lub zog laser theem ntawm cov khoom siv ua haujlwm laser. Thaum lub voj kev tawm tswv yim zoo raug ntxiv kom tsim nyog (los tsim cov kab noj hniav resonant), lub laser oscillation tso zis tuaj yeem tsim.

Laser Parts yog dab tsi?
Laser qhov chaw yog qhov chaw tsim khoom siv tshuab laser. Nws cov txheej txheem ntau lawm suav nrog kev ua cov ntaub ntawv, photolithography, etching, polishing thiab tu. Kev tsim cov txheej txheem ntawm cov khoom siv laser yog qhov yooj yim, tsis tas yuav tsum tau ua cov txheej txheem xws li txiav thiab stamping, thiab tuaj yeem ua tiav high-precision thiab high-efficiency ua. Yog li ntawd, laser qhov chaw yog dav siv nyob rau hauv semiconductor, optoelectronics, aerospace thiab lwm yam teb, xws li laser diodes, laser Cheebtsam, thiab lwm yam.

Qhov zoo ntawm Fiber Laser

Kev Ua Tau Zoo Tshaj Plaws Nruab Nrab

Tsis zoo li lwm cov lasers, fiber ntau lasers ua tiav lub teeb amplification hauv optical fibers, uas yog doped nrog tsawg lub ntiaj teb hlau ions xws li ytterbium (Yb{0}}), neodymium (Nd3+), thulium (Tm{2} }), praseodymium (Pr3+), los yog erbium (Er3+). Cov laser active ions tuaj yeem nqus tau feem ntau ntawm lub teeb pom kev zoo, thiab tom qab ntawd emit photons nrog cov yam ntxwv zaus ntawm kev txhawb nqa emission. Cov qauv yooj yim ntawm cov fibers ua rau siv ntau qhov kev ncua ntev dua li lwm hom laser. Qhov no muab lub siab optical nce.

Smart Feedback Loop los ntawm Fiber Bragg Gratings

Es tsis txhob siv cov pa iav dielectric, qhov kev tawm tswv yim kho qhov muag hauv fiber ntau lasers feem ntau yog muab los ntawm fiber ntau Bragg gratings, cov iav fiber ntau nrog cov ntsuas sib txawv refractive fusion-spliced nyob rau hauv ib ntus. Cov qauv ntu ntu no tuaj yeem cuam tshuam cov nqaj laser ntawm qee qhov wavelength thiab yog li dhau los ua cov kab noj hniav ntawm fiber ntau laser. Yog li, rau lub fiber ntau laser, qhov kho qhov muag kab noj hniav yog tiag tiag nyob rau hauv lub nce nruab nrab.

Robust Optical Cavity

Thaum tham txog fiber ntau lasers, ib qho pitfall kom tsis txhob yog tias fiber ntau lasers tsis sib npaug rau cov lasers uas muaj fiber ntau optical. Piv txwv li, nyob rau hauv fiber-coupled diode lasers, optical fibers yog ua hauj lwm tsuas yog rau lub beam xa lub hom phiaj thiab tsis koom nyob rau hauv lub physics ntawm stimulated emission. Yog li ntawd, txawm hais tias optical fibers yeej ua ke nrog lub tshuab laser, lawv tseem tsis muaj tag nrho cov zoo tshaj ntawm fiber ntau laser. Qhov tshwj xeeb sib xyaw ua ke kho qhov muag kab noj hniav nrog coiled fiber ntau raws li qhov nruab nrab qhov nruab nrab tsim cov kab noj hniav muaj zog thiab ruaj khov.

Compact footprint

Ib qho ntawm cov txiaj ntsig tseem ceeb ntawm fiber ntau lasers yog lawv cov qauv tsim. Piv nrog rau lawv cov rivals lawv ntaus kis las me me hneev taw ntawm kev sib piv cov khoom muaj zog. Qhov no yog vim cov fibers kho qhov muag yog khoov tau thiab tuaj yeem coiled rau hauv qhov chaw me me. Tsis tas li ntawd, qhov yooj ntawm optical fibers kuj ua rau muaj peev xwm ntxiv kev hloov kho ntawm txoj kev kho qhov muag, muab kev ywj pheej ntau dua hauv kev tsim rau ntau yam xwm txheej.

Siab tso zis zog

Txij li thaum qhov nce nruab nrab hauv fiber ntau lasers nyias nyias thiab hloov tau yooj yim, nws muaj peev xwm muaj cov fibers optical ob peb mais ntev, thiab li no ncav cuag qhov nce siab ntawm lub teeb pom kev zoo. Tsis tas li ntawd, vim qhov loj ntawm thaj chaw rau qhov ntim piv ntawm optical fibers, cov cua sov tsim los ntawm fiber ntau lasers tuaj yeem ua tau zoo dissipated. Yog li, fiber ntau lasers tuaj yeem ua haujlwm tsis tu ncua ntawm qib kilowatts yam tsis tas yuav tsum muaj cov tshuab cua txias.

Zoo heev Beam Quality

Nquag, laser beam zoo yog txhais raws li kev ntsuas ntawm yuav ua li cas nruj lub beam yuav tsom, thiab nws yog quantified los ntawm ib tug M2 yam, uas yog zoo tagnrho sib npaug rau 1 rau lub siab tshaj plaws beam zoo. Nyob rau hauv ib lub laser fiber ntau, ib hom fibers feem ntau muab qhov zoo tshaj plaws beam kev ua tau zoo, thiab tuaj yeem tsim kev siv tseem ceeb. Piv txwv li, nyob rau hauv laser txiav thiab vuam, ib tug siab beam zoo yuav tso cai rau ib tug ntev nyob deb ntawm lub workpiece thiab cov khoom tsom. Qhov kev teeb tsa no yuav tiv thaiv cov optics los ntawm cov khib nyiab thiab cov pa taws. Qhov tseem ceeb tshaj plaws, txoj kab uas hla txo qis tuaj yeem ua tsis tau tsuas yog ua kom zoo dua cov qauv tsim, tab sis kuj siv cov khoom siv kho qhov muag me me thiab pheej yig dua.

Kev ntseeg siab

Fiber lasers muaj kev ntseeg siab thiab yuav luag tsis muaj kev saib xyuas, thiab txij li txoj kev kho qhov muag yog nyob rau hauv cov khaubncaws sab nraud povtseg, cov nqaj laser tsis tshua muaj kev cuam tshuam rau sab nrauv. Yog li, fiber ntau laser feem ntau khav theeb zoo heev nyob rau hauv high-temperature thiab vibrational ua hauj lwm tej yam kev mob.

Hom Fiber Laser

Feem ntau hais lus, fiber ntau lasers tuaj yeem categorized siv cov hauv qab no:

Laser qhov chaw

Fiber lasers sib txawv raws li cov khoom uas lub laser qhov sib xyaw. Qee qhov piv txwv suav nrog ytterbium-doped fiber ntau lasers, thulium-doped fiber ntau lasers, thiab erbium-doped fiber ntau lasers. Txhua hom lasers no yog siv rau kev siv sib txawv vim lawv tsim cov wavelengths sib txawv.

Hom kev ua haujlwm

Ntau hom lasers tso tawm laser beam txawv. Laser beams tuaj yeem raug xa mus rau ntawm qhov teeb tsa rov ua dua kom ncav cuag lub zog siab tshaj plaws (pulsed fiber ntau lasers), xws li cov ntaub ntawv "q-hloov", "tau-hloov" thiab "mode-locked" lasers. Los yog, lawv tuaj yeem ua tsis tu ncua, txhais tau hais tias lawv tsis tu ncua xa tib lub zog (nruam-yoj fiber ntau lasers).

Laser zog

Lub zog laser yog qhia hauv watts thiab sawv cev rau lub zog nruab nrab ntawm lub teeb ci laser. Piv txwv li, koj tuaj yeem muaj 20W fiber ntau laser, 50W fiber ntau laser, thiab lwm yam. High-power lasers ua kom muaj zog ntau dua li lub zog qis zog lasers.

Hom

Hom yog hais txog qhov loj ntawm cov tub ntxhais (qhov twg lub teeb mus ncig) hauv cov fiber ntau optical. Muaj ob hom hom: ib hom fiber ntau lasers thiab ntau hom fiber ntau lasers. Cov tub ntxhais txoj kab uas hla rau ib hom lasers yog me me, feem ntau ntawm 8 thiab 9 micrometers, whereas nws loj dua rau multi-mode lasers, feem ntau ntawm 50 thiab 100 micrometers. Raws li txoj cai dav dav, ib hom lasers qhia lub teeb laser zoo dua thiab muaj lub teeb pom kev zoo dua.

Kev siv ntawm Fiber Laser

Deep Engraving

Cov txiaj ntsig tseem ceeb ntawm fiber ntau lasers dua lwm hom kev cim cim yog lub zog tso zis siab uas lawv muaj. Piv nrog rau lwm lub tshuab, lub laser fiber ntau tso zis tuaj yeem ua rau muaj kev txhim kho zoo kawg nkaus hauv kev kos lub sijhawm, kev ua haujlwm zoo, kev kos qhov tob, thiab cov cim zoo. Ib qho teeb meem tshwm sim nyob rau hauv cov ntawv sib sib zog nqus engraving yog qhov tsom ntawm lub laser. Raws li engravings mus tob thiab tob, lub focal point ntawm lub engraving ua ntxiv thiab ntxiv los ntawm lub lens ntawm lub laser. Qhov no tuaj yeem nthuav tawm cov teeb meem raws li qhov tawm ntawm lub ntsej muag laser yuav ua rau txo qhov tob ntawm qhov ua tiav.

Dub Annealed Marking

Black annealed marking yog txheej txheem ntawm kev siv lub laser beam rau lub hom phiaj thiab tom qab ntawd hloov qhov kev tsom xam kom tsuas yog ua kom sov. Lub laser tsis engraving tab sis theej tsim cov oxide zaj duab xis rau ntawm qhov chaw uas zoo nkaus li cov cim dub tab sis tsis tuaj yeem hnov rau qhov kov. Fiber lasers muaj txiaj ntsig zoo rau kev kos duab kos npe raws li lawv muab 3-axis beam tswj. Qhov no tso cai rau lub laser tuaj yeem kho qhov ua kom pom tseeb ntawm lub laser kom nthuav dav cov kab teeb hla ntawm thaj chaw dav. Qhov no yog qhov tseem ceeb hauv kev ua kom muaj qhov sib txawv ntawm qhov sib txawv, tsis muaj kev puas tsuaj rau qhov chaw ntawm lub workpiece.

Laser Txiav

Laser txiav yog ua los ntawm tsom lub teeb pom kev zoo los ntawm lub laser oscillator thiab irradiating txhua qhov chaw ruaj khov los ntawm chav irradiation kom yaj lub hom phiaj. Txij li thaum fiber ntau laser siv lub zog tso zis siab, fiber ntau laser excels ntawm laser txiav vim qhov ceev melting ntawm cov khoom. Nrog ceev melting, cov khoom raug txiav tam sim ntawd yam tsis muaj kev cuam tshuam rau cov khoom seem. Thaum txiav nrog fiber ntau laser, ntau yam khoom-los ntawm hlau mus rau yas- tuaj yeem txiav los ntawm fiber ntau laser.

Dab tsi yog qhov txawv ntawm Fiber Lasers thiab CO2 Lasers?

Qhov sib txawv tseem ceeb ntawm fiber ntau thiab CO2 lasers yog qhov chaw uas lub laser beam tsim. Nyob rau hauv fiber ntau lasers, lub laser qhov chaw yog silica iav tov nrog ib tug tsawg-lub ntiaj teb caij. Nyob rau hauv CO2 lasers, lub laser qhov chaw yog ib tug sib tov ntawm gases uas muaj xws li carbon dioxide.
Vim yog lub xeev ntawm lawv qhov chaw, fiber ntau lasers suav hais tias yog lub xeev cov lasers, thiab CO2 lasers yog suav tias yog roj-xeev lasers.
Cov chaw laser no kuj tsim cov wavelength sib txawv. Fiber lasers, piv txwv li, tsim luv wavelengths, nrog rau qee qhov piv txwv ntawm 780 nm thiab 2200 nm. CO2 lasers, ntawm qhov tod tes, tsim cov wavelengths ntev dua uas feem ntau nyob nruab nrab ntawm 9,600 nm thiab 10,600 nm.
Lawv siv rau cov ntawv thov sib txawv vim lawv qhov sib txawv wavelengths. Piv txwv li, 1064 nm fiber ntau lasers feem ntau yog nyiam rau kev siv hlau ua. Laser txiav yog qhov tshwj xeeb tshwj xeeb, qhov twg CO2 lasers feem ntau nyiam txiav cov hlau. CO2 lasers kuj teb zoo nrog cov ntaub ntawv organic.

Yuav Ua Li Cas Fiber Lasers Tsim?

Fiber lasers yog tsim los ntawm cov qauv tsim tshwj xeeb. Txhua yam uas cuam tshuam rau kev tsim laser yog tham hauv cov tshooj hauv qab no.

Laser Cavity Design hauv Fiber Lasers
Lub laser kab noj hniav yog qhov twg qhov nce nruab nrab yog nyob. Nws muaj ntau yam khoom siv kho qhov muag uas pab ua kom lub zog ntawm lub laser. Nyob rau hauv cov ntaub ntawv ntawm fiber ntau lasers, qhov nce nruab nrab yog fiber ntau optic augmented nrog tsawg-lub ntiaj teb ntsiab.

Fusion Splicing hauv Fiber Lasers
Fusion splicing yog txheej txheem ntawm splicing fiber optic cables ua ke kom lub teeb yuav dhau los ntawm lawv unhindered. Yog tias fusion spliced zoo, lub laser yuav tsim lub zog ntau dua.

Laser Diodes hauv Fiber Lasers
Laser diodes yog compact, zoo semiconductors uas hloov hluav taws xob lub zog rau hauv lub teeb laser. Cov khoom siv no tsim kom muaj qhov ci ntsa iab thiab spectrum siv los "tswj" cov doped fiber ntau.
Lub ntiaj teb tsis tshua muaj ions embedded nyob rau hauv lub doped fiber ces tau txais kev zoo siab los ntawm lub laser beams uas ua los ntawm lub laser diode twj tso kua mis qhov chaw. Kev nce qib siab yog proportional rau qhov kev zoo siab no. Lub peev xwm ntawm cov tshuaj doping - xws li ytterbium - los nqus lub teeb los ntawm cov twj tso kua mis lasers ua lub luag haujlwm hauv nws cov kev xaiv.

Dielectric Daim iav hauv Fiber Laser
Dielectric iav yog cov iav ua los ntawm ntau tshaj ib qho khoom siv reflective. Lawv ua rau daim iav muaj kev cuam tshuam ntau dua li cov iav ua los ntawm ib qho khoom siv. Fiber lasers siv dielectric tsom iav kom ntxiv qhov nce ntawm cov zis laser.

Distributed Feedback Lasers nyob rau hauv Fiber Lasers
Kev xa tawm tswv yim (DF) fiber ntau lasers muaj qhov tshwj xeeb zoo. Ib tug faib tawm tswv yim laser siv ib tug nce nruab nrab thiab ib tug periodic qauv raws li nws tag nrho cov resonator, ua raws li ib tug faib reflector nyob rau hauv lub laser kev khiav hauj lwm wavelength ntau yam. Ib theem hloov feem ntau yog nyob rau hauv nruab nrab ntawm no periodic qauv. Hauv qhov tseeb, cov qauv no ua haujlwm raws li kev sib txuas ntawm ob lub Bragg gratings nrog optical nce.
Feem ntau ntawm cov lus tawm tswv yim lasers siv ib hom resonator thiab yog fiber ntau lossis semiconductor lasers. Qhov kev xav tau faib rau hauv fiber ntau Bragg grating, uas ib txwm muaj qhov ntev ntawm ob peb millimeters lossis centimeters, tshwm sim nyob rau hauv rooj plaub ntawm fiber ntau laser.

Ob-Clad Fibers hauv Fiber Lasers
Ob-clad fiber ntau yog feem ntau nyob rau hauv high-power fiber lasers. Lub hauv paus ntawm ob-clad fiber yog doped nrog tsawg ntiaj teb dopants. Qhov xav tau beam zoo cwj pwm yog muab los ntawm tus qauv ib hom fiber ntau. Txawm li cas los xij, ib hom twj tso kua mis laser diodes yog qhov tsim nyog rau ib hom fiber ntau core. Tsim kom raug, txoj kab uas hla ntawm cov tub ntxhais no tso cai rau ib hom laser oscillation, uas ua rau lub teeb pom kev zoo.

Diffraction-Limited Beam Powers ntawm Fiber Lasers
Lub teeb diffraction-limited beam muaj qhov ci ntsa iab siab tshaj plaws, lossis radiance, rau lub zog kho qhov muag. "Diffraction-limited" yog siv los piav txog lub nqaj uas nws lub peev xwm los tsom mus rau qhov me me rau qhov muab wavelength tsuas yog txwv los ntawm qhov tsis muaj qhov sib txawv. Hauv lwm lo lus, nws muaj qhov zoo tshaj plaws beam zoo.

Ntev npaum li cas Fiber Laser Ntev?

Feem ntau cov chaw hauv online hais tias fiber ntau lasers kav ntev li 100, 000 teev thaum CO2 lasers dhau 30, 000 teev. Qhov no tsis yog tseeb kiag li. Cov lej no hais txog tus nqi hu ua "lub sijhawm nruab nrab ntawm kev ua tsis tiav" (MTBF), uas tsis zoo ib yam rau txhua qhov fiber ntau lasers. Hauv kev muaj tiag, koj yuav pom cov lej sib txawv rau ntau hom fiber ntau lasers.
MTBF ntsuas qhov kev ntseeg siab ntawm lub laser los ntawm kev qhia tias pes tsawg teev lub laser yuav tsum ua haujlwm ua ntej qhov tsis ua tiav. Nws tau txais los ntawm kev sim ntau lub laser units, thiab tom qab ntawd faib tag nrho cov sijhawm ua haujlwm los ntawm tag nrho cov kev ua tsis tiav.
Nov yog yam koj yuav tsum paub yog tias koj lub laser kev ua tsis tiav ntawm ib lub sijhawm no:
● Lub neej thaum ntxov:Yog hais tias fiber ntau laser muaj fabrication yuam kev, nws yuav muaj tsis ua hauj lwm thaum ntxov. Koj yuav tsum xyuas kom meej tias koj muaj kev yuav khoom lav uas npog fabrication yuam kev kom lub laser tuaj yeem hloov tau yam tsis muaj nqi.
●Lub neej li qub:Thaum koj tau dhau thawj lub sijhawm tseem ceeb ntawm lub neej thaum ntxov, tus nqi MTBF muab koj lub tswv yim zoo ntawm koj lub laser txoj kev ua tsis tiav. Lub siab MTBF yog qhov kev lees paub zoo tias txhua yam yuav mus zoo, tab sis tsis yog qhov lav. Koj tuaj yeem npaj rau kev ua tsis tiav thaum lub neej ib txwm muaj nyob hauv ntau txoj hauv kev: muaj lub laser seem uas yooj yim, xauj lub laser thaum koj li raug kho, lossis muaj kev lav phib xaub ntev.
● Thaum kawg ntawm lub neej:Thaum fiber ntau lasers nyob ze lawv lub neej kawg, txoj hauv kev tsis ua haujlwm nce siab heev. Txawm li cas los xij, kev lag luam zoo laser feem ntau tuaj yeem ua haujlwm dhau los ntawm nws cov MTBF.

Yuav Ua Li Cas Lub Hwj Chim ntawm Fiber Laser Scale?

Fiber lasers 'muaj peev xwm mus teev nyob rau hauv lub hwj chim yog txwv los ntawm Brillouin thiab Raman scattering raws li zoo raws li lub luv luv ntawm lub lasers lawv tus kheej. Ntau yam khoom, suav nrog amplifiers, keyboards, thiab cov ntsiab lus logic, xav tau cov kev teeb tsa uas tsis yog-linear.

Muaj ob chav kawm ntawm cov teebmeem nonlinear hauv optical fibers. Thawj qhov yog coj los ntawm Kerr nyhuv, lossis qhov kev siv zog ntawm qhov nruab nrab qhov ntsuas qhov ntsuas. Qhov tshwm sim no tshwm sim raws li ib qho ntawm peb qhov teebmeem, nyob ntawm seb hom teeb liab tawm tswv yim: cross-theem kev hloov pauv (CPM), tus kheej-theem kev hloov pauv (SPM), lossis plaub-yoj sib xyaw (FWM).

Qhov thib ob nonlinear nyhuv tshwm sim thaum qhov chaw kho qhov muag hloov qee qhov ntawm nws lub zog mus rau qhov nruab nrab nonlinear ntawm inelastic scattering. Xws li inelastic scattering tuaj yeem ua rau muaj tshwm sim xws li stimulated Brillouin scattering (SBS) thiab stimulated Raman scattering (SRS).

Txhua daim ntawv ntawm kev ua kom muaj zog tawg tuaj yeem ua rau muaj txiaj ntsig zoo rau cov fiber ntau. Nyob rau hauv ob qho tib si txheej txheem, yog hais tias qhov teeb meem fais fab nce siab tshaj ib qho chaw pib, qhov kev siv ntawm dispersed lub teeb nce exponentially. Vim hais tias ntawm qhov sib piv loj zaus hloov thiab qhov dav nce bandwidth, Raman amplification yog qhov zoo dua. Qhov sib txawv tseem ceeb ntawm lawv yog tias nyob rau hauv Brillouin, lub optical yoj cuam tshuam nrog tsawg zaus acoustic phonons, whereas nyob rau hauv Raman, qhov taw qhia optical yoj cuam tshuam nrog high-frequency optical phonons. Lwm qhov kev sib txawv tseem ceeb yog tias SRS tuaj yeem tshwm sim hauv ob qho kev qhia thaum SBS tsuas yog tshwm sim nyob rau hauv kev coj rov qab hauv cov fibers optical.

Ntev npaum li cas Fiber Laser Txiav?

Qhov tob ntawm fiber ntau laser txiav yog nyob ntawm ntau yam, nrog rau lub zog ntawm lub laser, hom khoom raug txiav, lub kaum sab xis ntawm kev txiav, qhov zoo ntawm lub lens tsom, thiab qhov ceev ntawm lub laser txav. .
Feem ntau, Fiber lasers tuaj yeem txiav cov hlau mus txog ob peb centimeters tuab. Txawm li cas los xij, qhov tseeb qhov tob uas Fiber laser txiav tuaj yeem sib txawv raws li cov ntawv thov tshwj xeeb thiab cov xwm txheej ntawm cov txheej txheem laser txiav.

Lub Fiber Laser Ua Haujlwm li cas (Thiab Nws Cov Cheebtsam) yog dab tsi?

Lub teeb yog tsim nyob rau hauv Laser Diodes
Lub laser diode emitting lub teeb yuav tsum tau pumped rau hauv fiber ntau laserLaser diodes hloov hluav taws xob rau hauv photons-los yog lub teeb-mus rau hauv lub fiber-optic cable. Vim li no, lawv tseem hu ua "tswj qhov chaw"
Txhawm rau tsim lub teeb, diodes siv ob lub tshuab hluav taws xob sib txawv:
● Thawj tus raug them zoo, uas txhais tau hais tias nws xav tau ib qho hluav taws xob ntxiv.
● Qhov thib ob yog them tsis zoo, uas txhais tau hais tias nws muaj ib qho hluav taws xob ntxiv, lossis ib qho hluav taws xob dawb.

Pump Light yog coj hauv Fiber-Optic Cable
Nyob rau hauv qhov xwm txheej, lub teeb mus rau txhua qhov chaw. Txhawm rau kom pom lub teeb rau hauv ib qho kev taw qhia thiab tau txais lub teeb ci laser, fiber ntau-optic cables siv ob yam tseem ceeb: cov tub ntxhais fiber ntau thiab cladding.
● Lub hauv paus yog qhov chaw uas lub teeb mus. Nws yog ua los ntawm silica iav thiab tsuas yog ib feem ntawm cov cable uas suav nrog lub ntiaj teb tsis tshua muaj.
● Cov cladding yog cov khoom uas nyob ib puag ncig lub hauv paus. Thaum lub teeb hits lub cladding, nws bounces rov qab rau hauv lub hauv paus. Qhov no tshwm sim vim hais tias lub cladding muab tag nrho cov sab hauv xav txog.

Lub teeb yog Amplified nyob rau hauv Laser Cavity
Raws li lub teeb twj tso kua mis mus los ntawm fiber ntau-optic cable, nws thiaj li nkag mus rau hauv lub laser kab noj hniav - ib cheeb tsam me me ntawm cable uas tsuas yog lub teeb ntawm ib lub wavelength tshwj xeeb tsim. Cov kws kho mob lub cev hais tias cov fiber ntau yog "doped" hauv cheeb tsam no vim tias nws tau raug tov nrog cov khoom tsis tshua muaj hauv ntiaj teb.
Raws li hais los ntawm doped fiber cuam tshuam nrog lub teeb, lawv cov electrons nce mus rau qib siab zog. Thaum lawv poob rov qab rau lawv lub xeev yooj yim, lawv tso tawm lub zog hauv daim ntawv ntawm photons lossis lub teeb. Lub cev engineers xa mus rau cov phenomena xws li "electron excitation" thiab "electron so".

Lub teeb laser ntawm ib qho tshwj xeeb wavelength yog tsim
Lub wavelength uas ua los ntawm doped fiber ntau txawv raws li lub doping lub caij ntawm lub laser kab noj hniav. Qhov no yog ib qho tseem ceeb heev, vim hais tias sib txawv wavelengths yog siv rau kev siv sib txawv. Cov khoom siv doping tuaj yeem yog erbium, ytterbium, neodymium, thulium, thiab lwm yam. Ytterbium-doped fiber ntau lasers, piv txwv li, tsim lub wavelength ntawm 1064 nm thiab siv rau cov ntawv thov xws li laser npav thiab laser tu.

Lub Laser Beam yog zoo li tus thiab tso tawm
Photons uas tawm ntawm lub resonant kab noj hniav tsim ib tug laser beam uas yog heev zoo collimated (los yog ncaj) vim lub fiber lub teeb coj lub zog. Nyob rau hauv qhov tseeb, nws yog heev collimated rau feem ntau laser daim ntaub ntawv.
Txhawm rau muab cov kab teeb ci laser ib qho kev xav tau, cov khoom sib txawv tuaj yeem siv tau, xws li lo ntsiab muag thiab kab teeb nthuav dav. Piv txwv li, peb cov fiber ntau lasers tau nruab nrog 254 hli focal ntev lens rau laser daim ntaub ntawv uas khawb rau hauv cov khoom (piv txwv li, laser engraving thiab laser texturing). Qhov no yog vim lawv qhov ntev focal ntev tso cai rau peb tsom mus rau lub zog ntau dua mus rau thaj chaw kom muaj kev txhoj puab heev ntawm laser ablation.

Dab tsi yog Beam Zoo ntawm Fiber Lasers?

Ib qho fiber ntau laser beam zoo nyob ntawm ob lub zog ntawm intracavity distortions thiab qee yam ntawm tus qauv resonator. Qhov zoo tshaj plaws, cov cuab yeej yuav tsim qhov hu ua Gaussian beam, tab sis qhov tseeb beam zoo yog ib txwm tsis zoo tag nrho. Qhov kev qhia lej rau qhov zoo meej beam zoo yog M2=1. Lub teeb pom kev zoo laser tsom ntau lub zog rau hauv qhov chaw me me. Qee cov txheej txheem zoo li laser welding zam beam zoo meej kom lawv tsis ablate ntau cov khoom. Txawm li cas los xij, feem ntau (xws li laser engraving thiab tu) xav tau cov kab teeb zoo.

Peb lub Hoobkas

Wuhan Hofei-link Technology Co., Ltd.(Ntawm no hu ua 'HofeiLink') tau tsim nyob rau hauv Wuhan lub nroog, lub npe hu ua optical hav ntawm Tuam Tshoj. Cov khoom siv kho qhov muag siab heev, kev sib txuas lus kho qhov muag thiab cov khoom siv kho qhov muag fiber ntau.

20231221153931f9b7cd0b0b504d388e5d36c54921694d

Cov ntawv pov thawj

202312211540333ccff570732b48ed99fead72877f5602

Qhov kawg FAQ Qhia rau Photodetector

Q: Dab tsi yog fiber ntau laser?

A: Fiber laser yog ib lub laser uas siv fiber ntau optical li qhov nruab nrab nce. Cov fiber ntau kho qhov muag yog doped nrog lub ntiaj teb tsis tshua muaj cov ntsiab lus, xws li erbium, ytterbium, thorium lossis praseodymium, thiab cov ntsiab lus tsis tshua muaj hauv ntiaj teb no zoo siab los ntawm lub teeb pom kev zoo, yog li ua tiav lub teeb amplification thiab tsim tawm laser.

Q: Dab tsi yog txoj hauv kev ua haujlwm ntawm fiber ntau laser?

A: Lub hauv paus ntsiab lus ua haujlwm ntawm fiber ntau lasers yog ua raws li kev txhawb nqa emission ntawm hluav taws xob. Thaum lub teeb twj tso kua mis raug txhaj rau hauv fiber ntau doped nrog lub ntiaj teb tsis tshua muaj cov ntsiab lus, cov ntsiab lus no zoo siab rau qib siab zog. Thaum cov ntsiab lus no rov qab mus rau qis zog, lawv emit lub teeb ntawm tib lub wavelength raws li lub twj tso kua mis teeb, amplifying lub optical teeb liab. Los ntawm kev tsim cov kab noj hniav resonant, laser oscillation tuaj yeem tsim tawm kom pom lub teeb laser txuas ntxiv.

Q: Dab tsi yog qhov zoo ntawm fiber ntau lasers?

A: Fiber lasers muaj ntau yam zoo, nrog rau kev ua haujlwm siab, siab beam zoo, lub neej ntev, txij nkawm-dawb, compactness thiab yooj. Vim tias cov tub ntxhais fiber ntau nyias nyias, lub zog muaj zog tuaj yeem ua tiav, muab fiber ntau lasers zoo hauv kev siv miniaturization thiab high-power.

Q: Nyob rau hauv dab tsi teb yog fiber ntau lasers siv?

A: Fiber lasers tau siv dav hauv ntau qhov chaw, suav nrog kev lag luam, kev sib txuas lus, kev kho mob, kev ua tub rog thiab kev tshawb fawb. Hauv kev ua lag luam, fiber ntau lasers yog siv rau kev ua haujlwm xws li txiav, vuam, kos thiab drilling. Hauv kev sib txuas lus, fiber ntau lasers yog siv los ua lub teeb ci rau fiber ntau optic kev sib txuas lus.

Q: Yuav ua li cas fiber ntau lasers piv rau lwm hom lasers?

A: Fiber lasers muaj ntau yam tshwj xeeb piv rau lwm hom lasers. Piv txwv li, qhov nce nruab nrab ntawm fiber ntau laser yog ib qho fiber ntau optical es tsis yog cov khoom siv los yog roj nruab nrab. Tsis tas li ntawd, fiber ntau lasers muaj cov kab teeb pom kev zoo thiab tsis tshua muaj thermal cuam tshuam, uas ua rau lawv muaj txiaj ntsig zoo hauv ntau daim ntawv thov.

Q: Yuav ua li cas xaiv lub fiber ntau laser?

A: Xaiv qhov zoo fiber ntau laser yuav tsum tau xav txog ntau yam, nrog rau yuav tsum tau laser wavelength, lub zog, beam zoo, stability, kev cia siab rau thiab nqi. Tsis tas li ntawd, cov kev cai tshwj xeeb ntawm daim ntawv thov yuav tsum tau txiav txim siab, xws li cov khoom yuav tsum tau ua, ua kom ceev, raug thiab txiav qhov tob.

Q: Yuav ua li cas tswj fiber ntau laser?

A: Kev saib xyuas ntawm fiber ntau lasers yog qhov yooj yim, vim lawv feem ntau nyob ntev thiab tsis muaj kev saib xyuas. Txawm li cas los xij, kev tshuaj xyuas tsis tu ncua ntawm cov xwm txheej ntawm fiber ntau optics thiab connectors yog tsim nyog. Tsis tas li ntawd, ua kom qhov chaw ua haujlwm ntawm lub laser huv si thiab tsis txhob kub thiab av noo ntau dhau kuj tseem ceeb rau kev tswj cov fiber ntau laser.

Q: Dab tsi yog qhov kev txhim kho yav tom ntej ntawm fiber ntau lasers?

A: Nrog kev nce qib txuas ntxiv ntawm optoelectronic thev naus laus zis, kev txhim kho yav tom ntej ntawm fiber ntau lasers yog mus rau lub zog siab dua, me me, kev ua haujlwm siab dua thiab kev siv ntau dua. Tsis tas li ntawd, fiber ntau lasers yuav nthuav dav lawv daim ntawv thov nyob rau hauv kev kho mob, tub rog thiab kev tshawb fawb teb.

Q: Lub laser fiber ntau ua li cas?

A: Fiber lasers nyob txhua qhov chaw hauv ntiaj teb niaj hnub no. Vim muaj qhov sib txawv wavelengths lawv tuaj yeem tsim, lawv tau siv dav hauv kev lag luam ib puag ncig los ua kev txiav, kos, vuam, tu, texturing, drilling thiab ntau ntxiv. Lawv kuj tau siv rau lwm yam xws li kev sib txuas lus thiab tshuaj.

Q: Qhov twg zoo dua CO2 lossis fiber ntau laser?

A: Yog tias koj tab tom nrhiav kos cov hlau, yam koj yuav tsum tau yuav yog fiber ntau laser. Yog tias koj tab tom nrhiav kos cov ntaub ntawv organic xws li textiles, ntoo, lossis cardboard, CO2 laser yog qhov kev xaiv zoo tshaj. Yog tias koj daim ntawv thov yog laser txiav cov hlau, koj yuav xav tau lub zog siab CW (nruam yoj) fiber ntau laser.

Q: Vim li cas fiber ntau lasers thiaj li kim?

A: Kev ua tau zoo thiab kev ua tau zoo: Fiber lasers paub txog lawv cov kev ua tau zoo thiab kev ua haujlwm zoo dua, uas ua rau cov kab teeb pom kev zoo dua, kev ua haujlwm nrawm dua, thiab kev siv hluav taws xob qis dua. Fiber lasers 'sophisticated nta thiab muaj peev xwm pab txhawb rau lawv cov nqi ntau dua.

Q: Dab tsi tuaj yeem ua fiber ntau laser tsis txiav?

A: Thib ob, fiber ntau laser txiav tshuab tsis tuaj yeem txiav MDF, uas feem ntau suav nrog fiberboard, ntoo fiber ntau, thiab cog fiber ntau, thiab qee cov ntaub ntawv yog ua los ntawm urea-formaldehyde resin thiab board ua los ntawm cov nplaum. Vim hais tias fiber ntau laser txiav tshuab yog nyob rau kub-ua tiav.

Q: Puas yog lub laser fiber ntau tsim nyog?

A: Kev nqus zoo dua ntawm cov hlau txhais tau tias lawv ua kom sov sai heev, ua rau cov txheej txheem laser tau zoo dua. Qhov no txhais tau tias yog tias koj tab tom nrhiav txiav lossis kos cov hlau - nyuaj ua nrog CO2 qis dua 450W - fiber ntau laser yog qhov kev xaiv zoo heev.

Q: Ntev npaum li cas fiber ntau laser yuav kav ntev?

A: Qhov tseeb, lub diode module hauv fiber ntau laser feem ntau kav peb zaug ntev dua li lwm cov thev naus laus zis. Feem ntau cov lasers muaj lub neej nyob ib ncig ntawm 30, 000 teev, uas feem ntau sib npaug li 15 xyoo siv. Fiber lasers muaj lub neej xav tau nyob ib ncig ntawm 100, 000 teev, uas txhais tau hais tias siv li 45 xyoo.

Q: Leej twg siv fiber ntau lasers?

A: Koj yuav pom lawv hauv ntau qhov kev lag luam, xws li tshuaj, kev sib txuas lus, tsheb, kho hniav thiab hluav taws xob. Fiber lasers muab cov txiaj ntsig hauv qab no rau kev kos, tu thiab lwm yam kev siv laser: Kev ruaj ntseg, ceev thiab ua haujlwm zoo. Beam zoo heev.

Q: Puas yog fiber ntau lasers poob lub zog dhau sijhawm?

A: Lub tshuab yuav muaj kev poob, thiab tib yam yog qhov tseeb ntawm fiber ntau laser txiav tshuab. Yuav muaj kev poob ntau dua los yog tsawg dua hauv cov txheej txheem siv mus ntev, xws li kev txiav qeeb qeeb thiab kev txiav tsis zoo.

Q: Ntev npaum li cas fiber ntau laser txiav?

A: Fiber laser txiav tshuab muaj peev xwm txiav txawv nyob ntawm lawv lub zog, tab sis yuav luag txhua lub tshuab laser fiber ntau tuaj yeem txiav cov ntawv hlau uas muaj txog li 13 hli tuab. Cov tshuab fiber ntau siv hluav taws xob ntau dua nrog 10kW lub zog tuaj yeem txiav cov hlau me me mus txog 2 hli thiab stainless hlau thiab txhuas mus txog 30 hli.

Q: Puas muaj fiber ntau laser vuam?

A: Fiber laser welding yog txheej txheem vuam uas siv lub laser beam ua lub tshav kub. Raws li cov cuab yeej tsis sib cuag, fiber ntau lasers yog qhov tsis tshua muaj txij nkawm thiab muab vuam ceev ceev. Lub laser beam yog heev leej thiab muaj ib tug tsawg tshav kub input, uas minimizes kev puas tsuaj rau cov khoom.

Q: Dab tsi yog roj fiber lasers siv?

A: Cov fiber ntau laser txiav cutter txiav cov xim xim xws li cov hlau tsis muaj hlau lossis txhuas daim hlau, thiab feem ntau siv nitrogen los ua cov pa roj kom txias thiab tiv thaiv. Cov pa roj carbon steel txiav siv cov pa kom txias thiab ua kom nrawm nrawm kom nrawm txiav.

Q: Yuav ua li cas fiber lasers pumped?

A: Cov txheej txheem feem ntau ua haujlwm yog hu ua cladding-pumping technology. Cladding-pumping ua rau kev siv lub zog siab, tus nqi qis, laser-diodes los nqus cov fibers. Lub cladding-pumped fiber muaj lub hauv paus tseem ceeb doped nrog lub ntiaj teb tsis tshua muaj lub caij xaiv.

Raws li ib qho ntawm cov ua fiber ntau laser thiab laser qhov chaw lag luam nyob rau hauv Suav teb, peb sov siab txais tos koj mus yuav cov nqi zoo fiber ntau laser thiab laser qhov chaw muag ntawm no los ntawm peb lub hoobkas. Tag nrho peb cov khoom thiab cov kev daws teeb meem yog nrog cov khoom zoo thiab cov nqi sib tw.
